Surface Mat
Common Specifications
| Grade | Areal Weight (g/m²) | Raw Material Composition | Standard Packaging Format | Remarks |
| C-HL20 | 20 | Medium-alkali glass fiber | 1m (W) × 250m (L) | Hand lay-up |
| C-HL30 | 30 | Medium-alkali glass fiber | 1m (W) × 250m (L) | — |
| C-FW30 | 30 | Medium-alkali glass fiber | 1m (W) × 250/500m (L) | Pipe winding |
| C-FW50 | 50 | Medium-alkali glass fiber | 1m (W) × 250/500m (L) | Pipe winding |
| EH-FW30 | 30 | Medium-alkali glass fiber | 1m (W) × 250/500m (L) | For pipe winding, high tensile strength; compatible with polyester & epoxy resins |
| EH-FW50 | 50 | Medium-alkali glass fiber | 1m (W) × 250/250m (L) | For pipe winding, high tensile strength; compatible with polyester & epoxy resins |
| CBG-20 | 20 | 50% Carbon Fiber & 50% Medium-alkali Glass Fiber | 1m (W) × 200m (L) | Corrosion-resistant |
| CBF-30 | 30 | 100% Carbon Fiber | 1m (W) × 100m (L) | Corrosion-resistant, anti-static |
Additional Notes
Width: Finished width is approx. 5cm, 20cm, 25cm; total available width up to 2 meters.
Fiberglass Surface Mat
Fiberglass surface mat is made from randomly oriented short-cut glass fibers or carbon fibers, formed via the wet-laid process and then bonded with a binder. It is mainly used for filament-wound pipes, storage tanks, etc., significantly improving the corrosion resistance, impermeability and surface finish of products, while extending their service life.
