Fiberglass Woven Roving

Short Description:

Fiberglass checkered fabric is a sheet-like plain or twill reinforced fabric woven directly from untwisted yarn, which provides excellent spatial stability during use. Twistless coarse gauze is suitable for various resin reinforcement systems, such as unsaturated polyester resin, vinyl resin, and epoxy resin. Fiberglass checkered cloth is widely used in hand lay up and mechanically formed products, such as ship, aircraft, and automotive parts, furniture, sports equipment, and other extensive application fields.

Send email to us

Product Detail

Fiberglass Woven Roving

Product Tags

Common Specifications

Grade	Glass Type	Weight (g/m²)	Tensile Strength ≥N/25mm (Warp)	Tensile Strength ≥N/25mm (Weft)	Weave	Moisture Content (%)	Combustible Content (%)
WR200	E	200+/-10	820	700	Plain	≤0.1	0.4–0.8
WR200B	E	200+/-10	820	700	Plain	≤0.1	0.4–0.8
WR270	E/ECR	270+/-14	1200	1000	Plain	≤0.1	0.4–0.8
WR300	E	300+/-15	1200	1200	Plain	≤0.1	0.4–0.8
WR300TM	E	300+/-15	1500	900	Plain	≤0.1	0.4–0.8
WR300B	E	360+/-18	1200	1250	Plain	≤0.1	0.4–0.8
WR360	E/ECR	400+/-20	1200	1150	Plain	≤0.1	0.4–0.8
WR400	E	400+/-20	1480	1380	Plain	≤0.1	0.4–0.8
WR400TM	E	325+/-16	1500	1500	Plain	≤0.1	0.4–0.8
WR400B	E	500+/-25	1200	1380	Plain	≤0.1	0.4–0.8
WR500	E	500+/-25	1800	1700	Twill	≤0.1	0.4–0.8
WR500T	E	500+/-25	1800	1600	Plain	≤0.1	0.4–0.8
WUDT500	E	500+/-25	100	2900	Plain	≤0.1	0.4–0.8
WUDL500	E	500+/-25	2600	350	Plain	≤0.1	0.4–0.8
WUDL530	E	530+/-27	3200	800	Plain	≤0.1	0.4–0.8
WR580	E/ECR	580+/-29	1900	1600	Plain	≤0.1	0.4–0.8
WR600	E	600+/-30	1900	1800	Plain	≤0.1	0.4–0.8
WR600B	E	600+/-30	1900	1850	Plain	≤0.1	0.4–0.8
WUDL600	E	600+/-30	3100	350	Plain	≤0.1	0.4–0.8
WR800	E	800+/-40	2600	2300	Plain	≤0.1	0.4–0.8
WR800A	E	864+/-43	2900	2700	Plain	≤0.1	0.4–0.8
WR1000	E	1000+/-50	2900	2900	Plain	≤0.1	0.4–0.8

Notes

● Standard Width: 1.0m, 1.25m, 1.27m (50")

● Min Width: 35mm

● Max Width: 3200mm

Previous: Fiberglass grid cloth composite felt

Next: Glass fiber four axis woven fabric

Fiberglass woven roving is a flat, plain or twill weave fabric made directly from non-twisted roving yarns. This structure provides excellent dimensional stability during use. The roving is suitable for various resin reinforcement systems, such as unsaturated polyester resin, vinyl ester resin, and epoxy resin. Fiberglass woven roving is widely used in hand lay-up and mechanical molding products, including boats, aircraft and automotive parts, furniture, sports equipment, and many other applications.
