Fiberglass Woven Roving Mat Combo (WRM)
Fiberglass woven roving mat combo is made by compounding a layer of uniformly randomly oriented chopped strand mat onto non-woven roving fabric, then stitching it together with a loop structure or bonding it with an adhesive. It is a fiberglass consumable material. The main end products made from fiberglass woven roving mat combo include: fiberglass boats, automotive exteriors, panels, car doors and profiles, etc.
Features of Fiberglass Woven Roving Mat Combo
● No adhesive, compatible with multiple resin systems
● Simplified molding process
● Improved production efficiency and reduced costs
Common Specifications
| Grade | Total Weight (g/m²) | Non-woven Roving Layer (g/m²) | Chopped Strand Layer (g/m²) | Stitching Thread (g/m²) |
| WRM200/150 | 359.5 | 200 | 150 | 9.5 |
| WRM300/300 | 609.5 | 300 | 300 | 9.5 |
| WRM500/300 | 809.5 | 500 | 300 | 9.5 |
| WRM500/450 | 959.5 | 500 | 450 | 9.5 |
| WRM600/300 | 909.5 | 600 | 300 | 9.5 |
| WRM600/450 | 960.71 | 600 | 450 | 10.71 |
| WRM800/300 | 1110.71 | 800 | 300 | 10.71 |
| WRM800/450 | 1260.71 | 800 | 450 | 10.71 |
| WRM1808 | 896.14 | 612 | 274.64 | 9.5 |
| WRM1810 | 926.65 | 612 | 305.15 | 9.5 |
| WRM1815 | 1080.44 | 612 | 457.73 | 10.71 |
| WRM2408 | 1132.35 | 847 | 274.64 | 10.71 |
| WRM2410 | 1162.86 | 847 | 305.15 | 10.71 |
| WRM2415 | 1315.44 | 847 | 457.73 | 10.71 |
| WRM2430 | 1762.71 | 847 | 900 | 15.71 |
Notes
● Standard Width: 125cm / 50"
● Corresponding Roll Weight: 50kg or 55kg
Packaging
● Each roll is wrapped with plastic film on a 3-inch diameter paper tube and packed in an individual paper box.
● 16 or 12 boxes per pallet.
No adhesive, suitable for various resin systems
Simplify the molding process
Provide production efficiency and reduce costs
