Alkali free glass fiber chopped felt
Product Features
● No binder, compatible with multiple resin systems
● Good mechanical properties
● Simple operation and low cost
Common Specifications
| Grade | Total Weight (g/m²) | Chopped Strand Layer (g/m²) | Stitching Thread (g/m²) | Surface Mat (g/m²) |
| M200 | 209.5 | 200 | 9.5 | / |
| M225 | 234.5 | 225 | 9.5 | / |
| M300 | 309.5 | 300 | 9.5 | / |
| MV300/45 | 354.5 | 300 | 9.5 | V30-45 |
| MC300/30 | 339.5 | 300 | 9.5 | C15-30 |
| M380 | 389.5 | 380 | 9.5 | / |
| MV380/45 | 434.5 | 380 | 9.5 | V45 |
| M400 | 409.5 | 400 | 9.5 | / |
| M450 | 459.5 | 450 | 9.5 | / |
| M600 | 609.5 | 600 | 9.5 | / |
| M900 | 909.5 | 900 | 9.5 | / |
Notes
● Standard Width: 120, 127, 160 cm; Max Width: 320 cm; Min Width: 3.5 cm
● Corresponding Roll Weight: 45, 48, 60 kg
Packaging
● Each roll is wrapped with plastic film on a 3–4 inch diameter paper tube and packed in an individual paper box.
● 16 or 12 boxes per pallet.
Fiberglass Stitched Chopped Strand Mat
Fiberglass stitched chopped strand mat is made by chopping fiberglass strands into 50mm lengths, laying them randomly and evenly, then stitching them together with a loop structure. The stitched mat has high tensile strength and is mainly recommended for pultrusion, continuous winding processes, and various panel production.
